HSKRC Brave HD5 Quadcopter Frame

This HSKRC Brave is a freestyle H frame designed around the DJI HD FPV system. The Air unit is mounted in the center of the frame to ensure perfect balance and the H frame allows for loads of room to mount your 30x30 or 20x20 flight gear.

Specifications

• Brand Name: HSKRC
• Name: Brave HD5 225
• Rack Type: Type H
• Wheelbase: 225mm
• Arm thickness: 5.0mm
• Upper plate (top plate): 2.0mm
• Lower plate (bottom plate): 3.0mm
• Camera board thickness: 2mm
• Splint thickness: 2mm
• Front and rear protection plate thickness: 2mm
• Arm link thickness: 2mm
• Frame weight: approx. 145g
• Maximum support blades: 5 inches
• Camera mounting space: 20MM
• Flight Stack mounting options: standard 30.5mm x 30.5mm or 20mm x 20mm
• FPV Compatibility: DJI FPV Air Unit
