Crazybee F4 Lite Whoop Flight Controller with VTX

Crazybee F4 Lite Whoop Flight Controller with VTX

Dhs. 150.00

FAST DIspatch & Global delivery
Quality Assured Brand Manufacturer

Receiver:

FrSky

FlySky

SKU: 75E-F80-4E1 Category: Racing & Flight Sim Hardware - Steering Wheels / Pedals / Shifters / Accessories. Tag: Shopify Collective, Unmanned Tech

Description
Product Reviews

This is the the flight controller used on the mobula6. It features a with a built in SPI receiver (FRsky / Flysky), MPU6000 gyro, betaflight OSD and a F411 MCU. All this packed into a tiny whoop form factor FC.

Specification

Crazybee F4 LiteFlight Controller Built-in ESC & Receiver & VTX	Frsky SPI RX version) CRAZYBEE F4 Lite Frsky version Firmware target: CrazybeeF4FR (Flysky SPI RX version) CRAZYBEE F4 Lite Flysky version Firmware target: CrazybeeF4FS MCU:STM32F411CEU6 (100MHZ, 512K FLASH) Sensor: MPU-6000(SPI connection) Board size: 28.5 * 28.5MM Power supply: 1S battery input (DC 2.9V-4.35V) Built-in 5A(each) Blheli_S 4in1 ESC Dshot600 ready Built-in Betaflight OSD(SPI Control) Built-in 5.8G VTX Built-in SPI Frsky/Flysky receiver Built-in 5V 1A BEC Built-in voltage detection
Onboard Frsky Receiver Version	SPI BUS receiver Frsky D8 compatible Compatible Non EU transmitter D8 model - Frsky_x_lbt Support EU LBT Radio Transmitter Channels: 8ch Failsafe support No ground interference ( Transmitter and receiver 1 m from the ground): 100m~200m
Onboard Flysky Receiver Version	SPI BUS receiver Protocol: AFHDS and AFHDS-2A Switchable Channels: 8ch(AFHDS) or 14ch(AFHDS-2A) No ground interference ( Transmitter and receiver 1 m from the ground): 100~200m Failsafe support
Onboard 5A BLheli_S 4in1 ESC	MCU upgraded to EFM8BB21 Power supply: 1S LiPo/LiPo HV Current: 5A continuous peak 6A (3 seconds) Support BLHeliSuite programmable Factory firmware: O_H_5_REV16_7.HEX Default protocol: DSHOT600
Onboard 5.8G 40CH 25mW VTX	Output power: 25mw Frequency: 40CH Input voltage: 3.3V 5.5V Current consumption: 300mA(type) Frequency: 5.8GHz 5bands 40 channels With Race band
